StreamLine Standing Seam is the only metal roofing panel with a patented no-siphon dry lock seam, with a unique reversing feature to allow installation of panels from both directions starting at any location.

The panel is designed with softer, less industrial lines to provide a more architecturally pleasing appearance.

Features & Benefits

  • 16" coverage
  • 26 Tru-Gauge
  • Factory-notched panels available
  • Vertical interlocking application: allowsinstallation from both directions starting atany location
  • Patented no-siphon lock seam
  • 1-1/8? vertical rib with flat top for ease of flashingattachment
  • Concealed fasteners: fasteners cannot leak
  • Pre-slotted fastener flange: allowsexpansion/contraction of panel
  • UL580 Class 90 wind uplift
  • UL Class A fire rated
  • 3:12 minimum pitch recommended: for lowerpitches please inquire
  • Standard panel lengths 2' to 35': for longerpanels, please inquire
  • Pan options: Flat pan, Accent ribs, Striations

Material Specifications

  • 26 gauge ARMOR TECH Painted Steel,.019? Steel (thickness prior to painting)Per ASTM A-792,Grade A, AZ50 Zincalume
  • 26 gauge Zincalume Steel,AZ55 Clear Acrylic Coating,Per ASTM A-792

Finishes

  • 14 Standard Colors
  • ARMOR TECH Paint System-the ultimate in exterior durabiity
  • Cool color pigments are specially designed to reflect infrared light, reducing heat gain todwelling, and conform with ENERGY STAR criteria
  • Superior quality, two coat SMP resin system at 1.1 mils
  • 40-year residential paint warranty

Colors
