The MS-Series is a fully crimped Standing Seam roof that is perfect for high wind areas and snow country. The butyl injected seam prevents water from entering the system, giving you a worry free roof for a life time.

Features & Benefits

  • 12" to 21" coverage options
  • 26, 24 & 22 gauge Tru-Gauge , .032 Aluminum and 24 gauge Bonderized (G-90)
  • 16 & 20 oz. Copper
  • Floating clip system: allows for expansion/contraction of panels in longer lengths
  • 1 ? vertical rib
  • Factory injected Butyl sealant
  • Concealed fasteners: fasteners cannot leak
  • UL580 Class 90: Dade impact: Dade 90: Dade 140 MPH: UL Class 4 hail
  • UL Class A Fire & Impact Rated
  • ASTM E-2140: ASTM-1646: ASTM 1680: ASTM 283: ASTM 330: ASTM 331: ASTM E-1592
  • Weather tightness warranty available (Contact TMP representative for details)
  • 1:12 minimum pitch recommended: for lower pitches please inquire
  • Standard panel lengths 2' to 65': for longer panels, please inquire
  • Onsite roll forming available
  • Pan options: Flat pan, Accent ribs, Striations
  • Retro-fit systems available

Material Specifications

  • 26 gauge Kynar 500 Painted Steel .019? (thickness prior to painting) G-90 Galvanized or AZ-50
  • 24 gauge Kynar 500 Painted Steel .0236? (thickness prior to painting) G-90 Galvanized or AZ-50
  • 26, 24 & 22 gauge bare Zincalume Plus with Clear Acrylic Coating-AZ-55
  • 22 gauge Kynar 500 Painted Steel .029? (thickness prior to painting G-90 Galvanized or AZ-50: Select colors, see data sheet for details
  • .032 Kynar 500 Painted Aluminum: Select colors, see data sheet for details
  • 24 gauge Bonderized (G-90)
  • 22 gauge Rusteel (Cold-Rolled)
  • 22 gauge Rusteel Plus (A606)
  • 16 and 20 ounce Copper

Finishes

  • 20 Standard Colors, 5 Metallic Colors and 5 Specialized Colors
  • Kynar 500 Paint System-the ultimate in exterior durabiity and color retention
  • Cool color pigments are specially designed to reflect infrared light, reducing heat gain to dwelling, and conform with ENERGY STAR criteria
  • Superior quality, two-coat, 70% resin finish, applied at a 1 mil. thickness
  • 40-year residential paint warranty
  • 20 and 30 year commercial paint warranty: (Contact TMP for warranty specifications)

Colors


Standard 24g Cool Kynar 500 Colors


Metallic Cool Kynar 500 & Specialized Materials
